Admin Thumbnails

This guide provides a reusable PHP snippet to enhance the WordPress admin experience by displaying featured images as thumbnails in list tables. This is particularly useful for post types like ‘Projects’ or ‘Services’ where a visual reference helps content managers identify items more efficiently.

We’ll walk through adding the PHP class, applying some simple styling with SCSS, and customizing it for different post types and taxonomies.

Our Blocksy child theme is configured to automatically include all PHP files from the inc/ directory. This makes adding new server-side functionality straightforward.

1. Add the PHP Code

   Create a new file named AdminThumbnailColumns.php inside the inc/ folder of your Blocksy child theme and add the following code.

   <?php

   namespace Best4u\BlocksyChild;

   if (!defined('ABSPATH')) {
       exit;
   }

   /**
    * Class Admin_Thumbnail_Columns
    *
    * Adds image thumbnail columns to admin post and taxonomy tables.
    */
   class Admin_Thumbnail_Columns
   {
       /**
        * Post types to display thumbnails for.
        *
        * @var array
        */
       private array $post_types = ['post', 'page', 'project'];

       /**
        * Taxonomies to display thumbnails for.
        *
        * @var array
        */
       private array $taxonomies = ['category'];

       /**
        * Class constructor. Hooks into theme setup.
        */
       public function __construct()
       {
           add_action('after_setup_theme', [$this, 'init']);
       }

       /**
        * Initializes thumbnail column registration.
        *
        * @return void
        */
       public function init(): void
       {
           $this->register_post_type_columns();
           $this->register_taxonomy_columns();
       }

       /**
        * Registers thumbnail columns for post types.
        *
        * @return void
        */
       private function register_post_type_columns(): void
       {
           foreach ($this->post_types as $post_type) {
               add_filter("manage_{$post_type}_posts_columns", [$this, 'add_post_thumbnail_column']);
               add_action("manage_{$post_type}_posts_custom_column", [$this, 'display_post_thumbnail_column'], 10, 2);
           }
       }

       /**
        * Adds a thumbnail column to the admin post list.
        *
        * @param array $columns
        * @return array
        */
       public function add_post_thumbnail_column(array $columns): array
       {
           $new_columns = [];
           foreach ($columns as $key => $value) {
               $new_columns[$key] = $value;
               if ($key === 'cb') {
                   $new_columns['thumbnail'] = __('Image', 'blocksy-child');
               }
           }
           return $new_columns;
       }

       /**
        * Displays the thumbnail image in the post column.
        *
        * @param string $column
        * @param int    $post_id
        * @return void
        */
       public function display_post_thumbnail_column(string $column, int $post_id): void
       {
           if ($column === 'thumbnail') {
               $thumbnail = get_the_post_thumbnail($post_id, [40, 40], ['class' => 'column-thumbnail-image']);
               echo $thumbnail ?: '<div class="column-thumbnail-image missing"></div>';
           }
       }

       /**
        * Registers thumbnail columns for taxonomies.
        *
        * @return void
        */
       private function register_taxonomy_columns(): void
       {
           foreach ($this->taxonomies as $taxonomy) {
               add_filter("manage_edit-{$taxonomy}_columns", [$this, 'add_taxonomy_thumbnail_column']);
               add_action("manage_{$taxonomy}_custom_column", function ($content, $column_name, $term_id) {
                   $this->display_taxonomy_thumbnail_column($column_name, $term_id);
               }, 10, 3);
           }
       }

       /**
        * Adds a thumbnail column to the taxonomy admin list.
        *
        * @param array $columns
        * @return array
        */
       public function add_taxonomy_thumbnail_column(array $columns): array
       {
           $new_columns = [];
           foreach ($columns as $key => $value) {
               $new_columns[$key] = $value;
               if ($key === 'cb') {
                   $new_columns['thumbnail'] = __('Image', 'blocksy-child');
               }
           }
           return $new_columns;
       }

       /**
        * Displays the thumbnail image in the taxonomy column.
        *
        * @param string $column_name
        * @param int    $term_id
        * @return void
        */
       public function display_taxonomy_thumbnail_column(string $column_name, int $term_id): void
       {
           if ($column_name !== 'thumbnail') {
               return;
           }

           $term_meta = get_term_meta($term_id, 'blocksy_taxonomy_meta_options', true);
           $thumb_id = $term_meta['image']['attachment_id'] ?? null;
           $image = $thumb_id ? wp_get_attachment_image($thumb_id, [40, 40], false, ['class' => 'column-thumbnail-image']) : null;

           echo $image ?: '<div class="column-thumbnail-image missing"></div>';
       }
   }

   new Admin_Thumbnail_Columns();

   Note

   How Taxonomy Thumbnails Work

   The display_taxonomy_thumbnail_column function is written to work with the Blocksy Post Types Extra extension, specifically when the ‘Taxonomy Customisations’ feature is enabled. It retrieves the thumbnail from the meta data saved by Blocksy.

   If you want to use an image from a different source, like a field created with Advanced Custom Fields (ACF), you’ll need to modify the function to fetch the image from the correct field.

   Once you save this file, the thumbnail column will automatically appear for the specified post types and taxonomies.

2. Add SCSS for Styling

   To ensure the thumbnails look good, add the following SCSS to your theme’s /assets/src/css/backend.scss file. This will style the thumbnail and provide a placeholder for items without a featured image. You can modify it as you see fit.

   .wp-list-table {
       .column-thumbnail {
           width: 80px;
           .column-thumbnail-image {
               height: 40px;
               width: 40px;
               object-fit: cover;
               background: #fff;
               padding: 4px;
               border: 1px solid var(--optionBorderColor);
               &.missing {
                   display: flex;
                   align-items: center;
                   justify-content: center;
                   line-height: 1;
                   &::before {
                       opacity: 0.25;
                   }
               }
           }
       }
   }

Customization

Note

You can easily customize which post types and taxonomies display the thumbnail column.

To change the targeted post types, simply edit the $post_types array at the top of the AdminThumbnailColumns.php file. For example, to add thumbnails to a custom post type called portfolio, you would modify the array like this:

private array $post_types = ['post', 'page', 'project', 'portfolio'];

Similarly, you can add other custom taxonomies to the $taxonomies array.
